XSCHEM to run in Windows online over Linux online
DESCRIPTION
XSCHEM is now part of coralEDA, a collection of EDA tools aiming to inter-operate with common protocols.(http://repo.hu/projects/coraleda)
Xschem is a schematic capture program, it allows to create a hierarchical representation of circuits with a top down approach . By focusing on interconnections, hierarchy and properties a complex system (IC) can be described in terms of simpler building blocks. A VHDL, Verilog or Spice netlist can be generated from the drawn schematic, allowing the simulation of the circuit. Key feature of the program is its drawing engine written in C and using directly the Xlib drawing primitives; this gives top speed performance, even on very big circuits. I have succesfully managed to simulate complete VLSI projects with this tool, both digital (Verilog / VHDL) and analog (Spice).
Schematics can be printed in SVG, PNG, PDF, formats. XSCHEM runs on Linux or other Unix-likes with Xorg server and on Windows with the Cygwin layer and required tools installed.
Features
- VHDL Verilog Spice
- EDA, Electronic Design Automation
- Schematic capture
- IC design
- Simulation
- HDL
- SPICE
Audience
End Users/Desktop, Engineering
User interface
X Window System (X11), Tk
Programming Language
C, Tcl, Yacc, AWK, Flex
This is an application that can also be fetched from https://sourceforge.net/projects/xschem/. It has been hosted in OnWorks in order to be run online in an easiest way from one of our free Operative Systems.
