5.4.1. Installation of Cross Binutils
Note
Go back and re-read the notes in the previous section. Understanding the notes labeled important will save you a lot of problems later.
Note
Go back and re-read the notes in the previous section. Understanding the notes labeled important will save you a lot of problems later.
It is important that Binutils be the first package compiled because both Glibc and GCC perform various tests on the available linker and assembler to determine which of their own features to enable.
The Binutils documentation recommends building Binutils in a dedicated build directory:
mkdir -v build cd build
mkdir -v build cd build
Note
In order for the SBU values listed in the rest of the book to be of any use, measure the time it takes to build this package from the configuration, up to and including the first install. To achieve this easily, wrap the commands in a time command like this: time { ./configure ... && ... && make install; }.
Note
In order for the SBU values listed in the rest of the book to be of any use, measure the time it takes to build this package from the configuration, up to and including the first install. To achieve this easily, wrap the commands in a time command like this: time { ./configure ... && ... && make install; }.
Note
The approximate build SBU values and required disk space in Chapter 5 does not include test suite data.
Note
The approximate build SBU values and required disk space in Chapter 5 does not include test suite data.
Now prepare Binutils for compilation:
../configure --prefix=/tools \
--with-sysroot=$LFS \
--with-lib-path=/tools/lib \
--target=$LFS_TGT \
--disable-nls \
--disable-werror
../configure --prefix=/tools \
--with-sysroot=$LFS \
--with-lib-path=/tools/lib \
--target=$LFS_TGT \
--disable-nls \
--disable-werror
The meaning of the configure options:
--prefix=/tools
This tells the configure script to prepare to install the Binutils programs in the /tools directory.
--with-sysroot=$LFS
For cross compilation, this tells the build system to look in $LFS for the target system libraries as needed.
--with-lib-path=/tools/lib
This specifies which library path the linker should be configured to use.
--target=$LFS_TGT
Because the machine description in the LFS_TGT variable is slightly different than the value returned by the config.guess script, this switch will tell the configure script to adjust Binutil's build system for building a cross linker.
--disable-nls
This disables internationalization as i18n is not needed for the temporary tools.
--disable-werror
This prevents the build from stopping in the event that there are warnings from the host's compiler.
Continue with compiling the package:
make
make
Compilation is now complete. Ordinarily we would now run the test suite, but at this early stage the test suite framework (Tcl, Expect, and DejaGNU) is not yet in place. The benefits of running the tests at this point are minimal since the programs from this first pass will soon be replaced by those from the second.
If building on x86_64, create a symlink to ensure the sanity of the toolchain:
case $(uname -m) in
x86_64) mkdir -v /tools/lib && ln -sv lib /tools/lib64 ;; esac
case $(uname -m) in
x86_64) mkdir -v /tools/lib && ln -sv lib /tools/lib64 ;; esac
Install the package:
make install
make install
